Home / Transmissions / Toyota / A140E
Toyota Source-verified model

Toyota A140E Transmission

Speeds 4
Type Automatic
Layout Transverse
ATF type Dexron II
ATF capacity (L) 5.6
ATF change (L) 2.5
Browse parts → Find transmission shops
Contribute info

This feature is in progress and will be available soon.

A140E
0.0/10
Support & Market Presence Index

How widely this transmission is used, documented and supported across the Go4Trans graph.

Diagram Parts Fitment Aliases Symptoms Related Sources Contribute

Exploded diagram & parts

Full A140E parts catalog →

Point at a part on the diagram (tap it on a phone) to see its position. Click it to see the parts.

070 070 · No. 1 034 034 · No. 2 3 3 · No. 3 530 530 · No. 4 036 036 · No. 5 520 520 · No. 6 7 7 · No. 7 778 778 · No. 8 179 179 · No. 9 037 037 · No. 10 311 311 · No. 11 211 211 · No. 12 13 13 · No. 13 046 046 · No. 14 555 555 · No. 15 337 337 · No. 16 17 17 · No. 17 975 975 · No. 18 879 879 · No. 19 122/106 122, 106 · No. 20 21 21 · No. 21 878 878 · No. 22 229 229 · No. 23 225 225 · No. 24 226 226 · No. 25 554 554 · No. 26 27 27 · No. 27 335 335 · No. 28 29 29 · No. 29 974 974 · No. 30 877 877 · No. 31 122/106 122, 106 · No. 32 146 146 · No. 33 876 876 · No. 34 231 231 · No. 35 232 232 · No. 36 050/233 050, 233 · No. 37 050 050 · No. 38 882 882 · No. 39 602 602 · No. 40 592 592 · No. 41 234 234 · No. 42 235 235 · No. 43 236 236 · No. 44 582 582 · No. 45 237 237 · No. 46 47 47 · No. 47 777 777 · No. 48 052 052 · No. 49 612 612 · No. 50 052 052 · No. 51 622 622 · No. 52 244 244 · No. 53 245 245 · No. 54 652 652 · No. 55 652 652 · No. 56 652 652 · No. 57 662 662 · No. 58 241 241 · No. 59 883 883 · No. 60 956 956 · No. 61 962 962 · No. 62 972 972 · No. 63 332 332 · No. 64 333 333 · No. 65 120/100 120, 100 · No. 66 144 144 · No. 67 873 873 · No. 68 665 665 · No. 69 888 888 · No. 70 654 654 · No. 71 654 654 · No. 72 654 654 · No. 73 888 888 · No. 74 584 584 · No. 75 241 241 · No. 76 246 246 · No. 77 247 247 · No. 78 248 248 · No. 79 594 594 · No. 80 604 604 · No. 81 889 889 · No. 82 892 892 · No. 83 150 150 · No. 84 130/100 130, 100 · No. 85 150 150 · No. 86 976 976 · No. 87 966 966 · No. 88 89 89 · No. 89 785 785 · No. 90 91 91 · No. 91 686/345 686, 345 · No. 92 687 687 · No. 93 415 415 · No. 94 680 +2 680, 266, 265 · No. 95 338 338 · No. 96 339 339 · No. 97 760 +3 760, 303, 685, 758 · No. 98 689 689 · No. 99 894 894 · No. 100 795 795 · No. 101 207 207 · No. 102 263 263 · No. 103 268269 268269 · No. 104 268269 268269 · No. 105 710 710 · No. 106 898 898 · No. 107 590 590 · No. 108 270 270 · No. 109 271 271 · No. 110 580 580 · No. 111 217 217 · No. 112 661 661 · No. 113 650 650 · No. 114 650 650 · No. 115 650 650 · No. 116 694 694 · No. 117 867 867 · No. 118 545 545 · No. 119 960 960 · No. 120 970 970 · No. 121 331 331 · No. 122 330 330 · No. 123 120/100 120, 100 · No. 124 140 140 · No. 125 996 996 · No. 126 127 127 · No. 127 128 128 · No. 128 129 129 · No. 129 446 446 · No. 130 861 861 · No. 131 863 863 · No. 132 142 142 · No. 133 122/106 122, 106 · No. 134 865 865 · No. 135 971 971 · No. 136 961 961 · No. 137 341 341 · No. 138 340 340 · No. 139 038 038 · No. 140 551 551 · No. 141 185 185 · No. 142 038 038 · No. 143 219 219 · No. 144 220 220 · No. 145 221 221 · No. 146 147 147 · No. 147 148 148 · No. 148 994 994 · No. 149 425 425 · No. 150 151 151 · No. 151 152 152 · No. 152 153 153 · No. 153 154 154 · No. 154 155 155 · No. 155 156 156 · No. 156 157 157 · No. 157 158 158 · No. 158 780 780 · No. 159 907 907 · No. 160 906B 906B · No. 161 908-1 908-1 · No. 162 906 906 · No. 163 164 164 · No. 164 165 165 · No. 165 166 166 · No. 166 167 167 · No. 167 168 168 · No. 168 169 169 · No. 169 170 170 · No. 170 171 171 · No. 171 172 172 · No. 172 410 410 · No. 173 072 072 · No. 174 326 326 · No. 175 736 736 · No. 176 375 375 · No. 177 730 730 · No. 178 274 274 · No. 179 273 273 · No. 180 735 735 · No. 181 075 075 · No. 182 075 075 · No. 183 399 399 · No. 184 681 681 · No. 185 696 696 · No. 186 895 895 · No. 187 699 699 · No. 188 280 280 · No. 189 281 281 · No. 190 712 712 · No. 191 796 796 · No. 192 896 896 · No. 193 362 362 · No. 194 909 909 · No. 195 362/487 362, 487 · No. 196 195 195 · No. 197 198 198 · No. 198 199 199 · No. 199 200 200 · No. 200 201 201 · No. 201 992 992 · No. 202 203 203 · No. 203 204 204 · No. 204 726 726 · No. 205 206 206 · No. 206 207 207 · No. 207 208 208 · No. 208 740 740 · No. 209 421 421 · No. 210 300/765 300, 765 · No. 211 076 076 · No. 212 293 293 · No. 213 291 291 · No. 214 292 292 · No. 215 847 847 · No. 216 716 716 · No. 217 720 720 · No. 218 289 289 · No. 219 288 288 · No. 220 290 290 · No. 221 725 725 · No. 222 793 793 · No. 223 076 076 · No. 224 999-4 999-4 · No. 225 226 226 · No. 226 422 422 · No. 227 786 786 · No. 228

Parts categories

View all parts →
Kits
Kits
64 parts
Valve body & solenoids
Valve body & solenoids
25 parts
Electrical
Electrical
11 parts
Filters & pans
Filters & pans
6 parts
Seals & gaskets
Seals & gaskets
33 parts
Bushings, bearings & thrust
Bushings, bearings & thrust
62 parts
Bands & servos
Bands & servos
2 parts
Pump
Pump
11 parts
Friction & steel
Friction & steel
48 parts
Planetary & hard parts
Planetary & hard parts
148 parts
Hardware & other
Hardware & other
62 parts
Sell A140E parts on Go4TransStart selling →

Vehicle fitment explorer

Confirmed vehicle applications. Every row is drawn from our source-verified fitment database.

15 applications · 1 make · 1983–2004 Toyota 15

Make Model Year Drive Engine
Toyota Camry 1992-2001 4 Spd FWD L4 2.2L
Toyota Camry 1987-2001 2.0, 2.2
Toyota Camry 1983-2004 4 Spd FWD L4 1.8/2.0/ 2.2L
Toyota Camry 1983-1986 1.8, 2.0
Toyota Camry 4 Spd FWD 1.8L, 2.0L, 2.0L TD
Toyota CAMRY GRACIA 2000-2001 4 Spd FWD L4 2.0/2.2L V6 3.0L
Toyota Camry Solara 1999-2001 4 Spd FWD L4 2.2L
Toyota Carina 1991 4 Spd FWD 2.0L
Toyota Celica 1994-1999 2.2
Toyota Celica 4 Spd FWD 2.0L
Toyota Celica GT 1994-1999 4 Spd FWD L4 2.2L
Toyota Celica GT 1994-1999 4 Spd FWD L4 2.0L
Toyota MR2 1985-1986 1.6
Toyota Solara 1999-2001 2.2
Toyota Solara 1998-2001 4 Spd FWD L4 2.2L

Other and alternative codes of this transmission

＋ Contribute

This feature is in progress and will be available soon.

No aliases recorded yet — be the first to contribute one. Contribute →

verified naming OEM designation source name

Common problems & symptoms

Problems and symptoms reported for this transmission, compiled from repair sources. Not a complete list.

!
Forward clutch pack failure
The forward clutch pack burns up or wears out, leaving the vehicle with no drive in any forward range; this is often accelerated by low-fluid overheating.
