Home / Transmissions / Toyota / A750F
Toyota Source-verified model

Toyota A750F Transmission

Speeds 5
Type Automatic
Drive 4WD
ATF type Toyota Genuine ATF WS
ATF change (L) 1.7
Browse parts → Find transmission shops
Contribute info

This feature is in progress and will be available soon.

A750F
0.0/10
Support & Market Presence Index

How widely this transmission is used, documented and supported across the Go4Trans graph.

Diagram Parts Fitment Aliases Symptoms Related Sources Contribute

Exploded diagram & parts

Full TB-50LS parts catalog →

Point at a part on the diagram (tap it on a phone) to see its position. Click it to see the parts.

776 776 · No. 1 2 2 · No. 2 750 750 · No. 3 070 070 · No. 4 034 034 · No. 5 311 311 · No. 6 530 530 · No. 7 530 530 · No. 8 036 +2 036, 520, 310 · No. 9 210 210 · No. 10 211 211 · No. 11 893 893 · No. 12 957 957 · No. 13 339-1 +2 339-1, 966, 976 · No. 14 219/339 219, 339 · No. 15 336 +5 336, 337, 965, 555, 975, 338 · No. 16 985 985 · No. 17 879 879 · No. 18 126/106 126, 106 · No. 19 878/146 878, 146 · No. 20 228 228 · No. 21 229 229 · No. 22 554 554 · No. 23 24 24 · No. 24 777 777 · No. 25 334/335 334, 335 · No. 26 964 964 · No. 27 974 974 · No. 28 984 984 · No. 29 877 877 · No. 30 149 149 · No. 31 128/108 128, 108 · No. 32 148/876 148, 876 · No. 33 232 232 · No. 34 233 233 · No. 35 574 574 · No. 36 234 234 · No. 37 235 235 · No. 38 575/051 575, 051 · No. 39 051-1 051-1 · No. 40 244 244 · No. 41 576/052 576, 052 · No. 42 052-1 052-1 · No. 43 150 150 · No. 44 130/110 130, 110 · No. 45 151 151 · No. 46 549 549 · No. 47 891 891 · No. 48 245 245 · No. 49 285 285 · No. 50 663 663 · No. 51 652-1 652-1 · No. 52 53 53 · No. 53 247/872 247, 872 · No. 54 144 144 · No. 55 124/104 124, 104 · No. 56 145 145 · No. 57 874 +2 874, 883, 972 · No. 58 333 +3 333, 962, 332, 632 · No. 59 665/286 665, 286 · No. 60 654/654-1 654, 654-1 · No. 61 887 887 · No. 62 249 249 · No. 63 579 579 · No. 64 053 053 · No. 65 582 582 · No. 66 238 238 · No. 67 240 240 · No. 68 241 241 · No. 69 996 996 · No. 70 378 378 · No. 71 996 996 · No. 72 378 378 · No. 73 490 490 · No. 74 493 493 · No. 75 370 370 · No. 76 436 436 · No. 77 262 262 · No. 78 760 760 · No. 79 263 263 · No. 80 264 264 · No. 81 265 265 · No. 82 897 897 · No. 83 898 898 · No. 84 698 698 · No. 85 271 271 · No. 86 770 770 · No. 87 066 066 · No. 88 074 074 · No. 89 602/592 602, 592 · No. 90 868 +2 868, 590, 215 · No. 91 216 216 · No. 92 580 580 · No. 93 610 610 · No. 94 132/112 132, 112 · No. 95 340 +4 340, 979, 969, 871, 341 · No. 96 547 547 · No. 97 861 861 · No. 98 100 +2 100, 120, 140 · No. 99 438 438 · No. 100 370 370 · No. 101 945 945 · No. 102 446 446 · No. 103 781 781 · No. 104 797-1 797-1 · No. 105 761C 761C · No. 106 925 925 · No. 107 108 108 · No. 108 109 109 · No. 109 110 110 · No. 110 950 950 · No. 111 112 112 · No. 112 113 113 · No. 113 935 935 · No. 114 115 115 · No. 115 116 116 · No. 116 347 347 · No. 117 991-4 991-4 · No. 118 072 072 · No. 119 410 410 · No. 120 207 207 · No. 121 995-1 995-1 · No. 122 995-6 995-6 · No. 123 995-3 995-3 · No. 124 995-4 995-4 · No. 125 960 +4 960, 331, 330, 545, 970 · No. 126 284/890 284, 890 · No. 127 669 669 · No. 128 658-1 658-1 · No. 129 658 658 · No. 130 658-1/284-1 658-1, 284-1 · No. 131 668/889 668, 889 · No. 132 060 060 · No. 133 604 604 · No. 134 060 060 · No. 135 594 594 · No. 136 154 154 · No. 137 114 114 · No. 138 428 428 · No. 139 140 140 · No. 140 453 453 · No. 141 142 142 · No. 142 421 421 · No. 143 422 422 · No. 144 145 145 · No. 145 072 072 · No. 146 991-3 991-3 · No. 147 991-8 991-8 · No. 148 379 379 · No. 149 994 994 · No. 150 991-2 991-2 · No. 151 638 638 · No. 152 740 740 · No. 153 010 010 · No. 154 991-2 991-2 · No. 155 799 799 · No. 156 155 155 · No. 157 253 253 · No. 158 254 254 · No. 159 255 255 · No. 160 674 674 · No. 161 248 248 · No. 162 058 058 · No. 163 584 584 · No. 164 250 250 · No. 165 251 251 · No. 166 884 884 · No. 167 977 977 · No. 168 967 967 · No. 169 329 329 · No. 170 328-1 328-1 · No. 171 329-1 329-1 · No. 172 329-2/967-1 329-2, 967-1 · No. 173 328-2 328-2 · No. 174 967-2 967-2 · No. 175 782 782 · No. 176 741M 741M · No. 177 450 450 · No. 178 425 425 · No. 179 426 426 · No. 180 300/765 300, 765 · No. 181 991-7 991-7 · No. 182 492 492 · No. 183

Parts categories

View all parts →
Kits
Kits
18 parts
Valve body & solenoids
Valve body & solenoids
16 parts
Electrical
Electrical
3 parts
Filters & pans
Filters & pans
2 parts
Seals & gaskets
Seals & gaskets
9 parts
Bushings, bearings & thrust
Bushings, bearings & thrust
50 parts
Pump
Pump
4 parts
Friction & steel
Friction & steel
46 parts
Planetary & hard parts
Planetary & hard parts
34 parts
Hardware & other
Hardware & other
33 parts
Sell A750F parts on Go4TransStart selling →

Vehicle fitment explorer

Confirmed vehicle applications. Every row is drawn from our source-verified fitment database.

32 applications · 3 makes · 1998–2016 Toyota 23 · Lexus 6 · Suzuki 3

Make Model Year Drive Engine
Lexus GX 470 2003-2009 5 Spd AWD V8 4.7L
Lexus GX 470 2003-2009 4.7
Lexus GX 470 2003-2007 5 Spd 4x4 V8 4.7L
Lexus LX470 2003-2007 5 Spd 4x4 V8 4.7L
Lexus LX470 2003-2007 5 Spd AWD V8 4.7L
Lexus LX470 2003-2007 4.7
Suzuki Grand Vitara 2006-2012 2.7, 3.2
Suzuki Vitara 2006-2008 2.7
Suzuki XL-7 2004-2007 2.7
Toyota 4 Runner 2005-2007 5 Spd 4x4 V6 4.0L V8 4.7L
Toyota 4 Runner 2003-2015 4.0, 4.7
Toyota 4 Runner 2003-2004 5 Spd 4x4 V8 4.7L
Toyota FJ Cruiser 2007-2014 4.0
Toyota FJ Cruiser 2007 5 Spd 4x4 V6 4.0L
Toyota FJ Cruiser 2006-2016 5 Spd 4X4 V6 4.0L
Toyota FORTUNER 2007-2014 5 Spd R/AWD L4 3.0L V6 4.0L V8 4.7L
Toyota HILUX/SW4 2002-2012 5 Spd R/AWD L4 3.0L V6 4.0L V8 4.7L
Toyota Land Cruiser 2003-2007 5 Spd 4x4 V8 4.7L
Toyota Land Cruiser 2003-2007 4.7
Toyota Land Cruiser 1998-2016 5 Spd AWD L4 3.0L V6 4.0L V8 4.7L
Toyota LAND CRUISER 200 2012-2014 5 Spd AWD V6 4.0L V8 4.7L
Toyota MARK X 2004-2009 5 Spd R/AWD V6 2.5L
Toyota PICKUP/TACOMA 2005-2007 5 Spd 4X4 V6 4.0L
Toyota Sequoia 2005-2007 5 Spd 4x4 V8 4.7L
Toyota Sequoia 2004-2008 4.6, 4.7
Toyota Tacoma 2005-2015 4.0
Toyota Tacoma / Pickup 2005-2014 5 Spd R/AWD V6 4.0L
Toyota Tacoma / Pickup 2005-2009 5 Spd 4x4 V6 4.0L
Toyota Tundra 2005-2014 4.0, 4.6, 4.7
Toyota Tundra 2005-2007 5 Spd 4X4 V8 4.7L
Toyota Tundra 2005-2006 5 Spd 4x4 V8 4.7L
Toyota Tundra 1999-2016 5 Spd RWD V6 4.0L V8 4.7L
