Home / Transmissions / Hyundai Motor Group / A4CF2
Hyundai Motor Group Source-verified model

Hyundai Motor Group A4CF2 Transmission

Speeds 4
Drive FWD
Type Automatic
ATF type SP-III
ATF capacity (L) 6.6
Max torque 230 Nm
Weight 74.1 kg
Browse parts → Find transmission shops
Contribute info

This feature is in progress and will be available soon.

A4CF2
0.0/10
Support & Market Presence Index

How widely this transmission is used, documented and supported across the Go4Trans graph.

3resources
Diagram Parts Fitment Aliases Symptoms Related Sources Contribute

Exploded diagram & parts

Full A4CF1 parts catalog →

Point at a part on the diagram (tap it on a phone) to see its position. Click it to see the parts.

776 776 · No. 1 369 369 · No. 2 774-1 774-1 · No. 3 750 750 · No. 4 070 070 · No. 5 034 034 · No. 6 311 311 · No. 7 530 530 · No. 8 530 530 · No. 9 036 036 · No. 10 777 777 · No. 11 520 520 · No. 12 778 778 · No. 13 179 179 · No. 14 310 310 · No. 15 211* 211* · No. 16 178 178 · No. 17 670 670 · No. 18 551 551 · No. 19 340 340 · No. 20 341 341 · No. 21 961 961 · No. 22 971 971 · No. 23 981 981 · No. 24 341-1 341-1 · No. 25 865 865 · No. 26 880 880 · No. 27 122/102 122, 102 · No. 28 142 142 · No. 29 864* 864* · No. 30 219 219 · No. 31 571 571 · No. 32 710 710 · No. 33 279 279 · No. 34 35 35 · No. 35 711 711 · No. 36 279 279 · No. 37 795 795 · No. 38 436 436 · No. 39 273 273 · No. 40 730/274 730, 274 · No. 41 712 712 · No. 42 281 281 · No. 43 276*/280 276*, 280 · No. 44 760 760 · No. 45 338 338 · No. 46 339 339 · No. 47 967 967 · No. 48 977 977 · No. 49 987 987 · No. 50 893 893 · No. 51 857 857 · No. 52 155* 155* · No. 53 134/114 134, 114 · No. 54 884 884 · No. 55 154 154 · No. 56 885 885 · No. 57 662 662 · No. 58 883 883 · No. 59 285 285 · No. 60 077 077 · No. 61 291 291 · No. 62 716 716 · No. 63 720 720 · No. 64 786 786 · No. 65 289 289 · No. 66 288 288 · No. 67 076 076 · No. 68 438 438 · No. 69 698 698 · No. 70 699 699 · No. 71 72 72 · No. 72 73 73 · No. 73 74 74 · No. 74 75 75 · No. 75 76 76 · No. 76 77 77 · No. 77 78 78 · No. 78 79 79 · No. 79 652/216 652, 216 · No. 80 584/216 584, 216 · No. 81 056/248 056, 248 · No. 82 614/056 614, 056 · No. 83 056 056 · No. 84 056/247 056, 247 · No. 85 246 246 · No. 86 594 594 · No. 87 580 580 · No. 88 867 867 · No. 89 124/104 124, 104 · No. 90 144 144 · No. 91 92 92 · No. 92 93 93 · No. 93 94 94 · No. 94 95 95 · No. 95 96 96 · No. 96 97 97 · No. 97 996-1 996-1 · No. 98 996 996 · No. 99 996 996 · No. 100 342 342 · No. 101 102 102 · No. 102 207 207 · No. 103 992 992 · No. 104 740 740 · No. 105 435 435 · No. 106 347 347 · No. 107 108 108 · No. 108 994 994 · No. 109 410 410 · No. 110 972 972 · No. 111 962 962 · No. 112 956 956 · No. 113 874 874 · No. 114 040 040 · No. 115 116 116 · No. 116 117 117 · No. 117 118 118 · No. 118 119 119 · No. 119 120 120 · No. 120 121 121 · No. 121 130/110 130, 110 · No. 122 123 123 · No. 123 124 124 · No. 124 995-3 995-3 · No. 125 126 126 · No. 126 425 +4 425, 426, 421, 422, 427 · No. 127 446 446 · No. 128 991-2 991-2 · No. 129 130 130 · No. 130 010 010 · No. 131 132 132 · No. 132 843 843 · No. 133 991-4 991-4 · No. 134 185 185 · No. 135 181 181 · No. 136 137 137 · No. 137 765/300 765, 300 · No. 138 140 140 · No. 139 120/100 120, 100 · No. 140 141 141 · No. 141 980 980 · No. 142 331-1 331-1 · No. 143 970 970 · No. 144 960 960 · No. 145 550 550 · No. 146 556 556 · No. 147 232 232 · No. 148 149 149 · No. 149 759 759 · No. 150 151 151 · No. 151 152 152 · No. 152

Parts categories

View all parts →
Kits
Kits
77 parts
Valve body & solenoids
Valve body & solenoids
35 parts
Electrical
Electrical
17 parts
Filters & pans
Filters & pans
13 parts
Seals & gaskets
Seals & gaskets
39 parts
Bushings, bearings & thrust
Bushings, bearings & thrust
260 parts
Bands & servos
Bands & servos
5 parts
Pump
Pump
11 parts
Friction & steel
Friction & steel
135 parts
Planetary & hard parts
Planetary & hard parts
183 parts
Hardware & other
Hardware & other
170 parts
Sell A4CF2 parts on Go4TransStart selling →

Vehicle fitment explorer

Confirmed vehicle applications. Every row is drawn from our source-verified fitment database.

34 applications · 2 makes · 2000–2016 Hyundai 20 · Kia 14

Make Model Year Drive Engine
Hyundai ACCENT 2000-2012 4 Spd FWD L4 1.3/1.4/1.5/1.6L
Hyundai Accent (Non-USA) 2000-2011 1.5, 1.6
Hyundai AVANTE HD/MD 2006-2012 4 Spd FWD L4 1.6/2.0L
Hyundai Avante MD/HD (Non-USA) 2006-2012 1.6, 2.0
Hyundai Avega (Non-USA) 2011-2012 1.6
Hyundai ELANTRA 2007-2012 4 Spd FWD L4 1.6/1.8/2.0L
Hyundai Elantra 2006-2011 2.0
Hyundai Elantra 2006-2007 4 Spd FWD L4 2.0L
Hyundai Getz (Non-USA) 2006-2009 1.4
Hyundai Getz/Click 2006 4 Spd FWD 1.6L, 2.0L, 1.6LD
Hyundai i20 2008-2014 4 Spd FWD L4 1.4/1.6L
Hyundai i20 (Non-USA) 2008-2011 1.4, 1.6
Hyundai i20 5 Door Comfort 2008 4 Spd FWD 1.4L Petrol
Hyundai i30 2007-2012 4 Spd FWD L4 1.4/1.6/2.0L
Hyundai i30 2007 4 Spd FWD 1.6L, 2.0L, 1.6CRD
Hyundai i30 (Non-USA) 2007-2011 1.4, 1.6, 2.0
Hyundai MOINCA 2009-2013 4 Spd FWD L4 1.8L
Hyundai Moinca (Non-USA) 2009-2012 1.8
Hyundai VERNA 2007-2016 4 Spd FWD L4 1.4/1.5/1.6L
Hyundai Verna (Non-USA) 2005-2012 1.4, 1.5, 1.6
Kia C'eed / Pro_C'eed (Non-USA) 2007-2012 1.6, 2.0
Kia Carens (Non-USA) 2009-2012 1.6
Kia CEE'D 2007-2011 4 Spd FWD L4 1.6L 2.0L
Kia CERATO 2005-2010 4 Spd FWD L4 1.6L/2.0L
Kia Cerato (Non-USA) 2005-2011 1.6, 2.0
Kia Forte 2009-2014 4 Spd FWD L4 1.6L 2.0L
Kia Forte (Non-USA) 2008-2012 1.6, 2.0
Kia PRIDE 2005-2014 4 Spd FWD L4 1.4/1.5/1.6L
Kia Pride (Non-USA) 2005-2012 1.4, 1.5, 1.6
Kia Soul 2008-2014 4 Spd FWD L4 1.6L/2.0L
Kia Soul (Non-USA) 2008-2012 1.6, 2.0
Kia Spectra 2006-2007 4 Spd FWD L4 2.0L
Kia Spectra / Spectra5 2006-2009 4 Spd FWD L4 2.0L
Kia Spectra / Spectra5 2004-2009 2.0

Other and alternative codes of this transmission

＋ Contribute

This feature is in progress and will be available soon.

No aliases recorded yet — be the first to contribute one. Contribute →

verified naming OEM designation source name

Common problems & symptoms

Problems and symptoms reported for this transmission, compiled from repair sources. Not a complete list.

!
Pressure regulator valve/bore wear
Continuous oscillation of the pressure regulator valve wears its bore, causing unstable line pressure that produces soft or harsh shifts and can secondarily damage clutches.
!
Boost valve/sleeve wear
Oscillation of the boost valve within its sleeve wears a leak path for EPC and reverse pressure, causing insufficient line rise in Drive and excessively high reverse pressure.
!
TCC regulator valve wear
Wear at the torque converter clutch regulator valve and bore allows pressure to leak, causing converter shudder/slip, poor TCC apply/release, and overheating.
